The aircraft clean water truck with a capacity of 4m³ has a water flow rate of ≥150L/min. The shell of the clean water box is made of high-quality stainless steel plate with a thickness of 4.5mm, made of S31603 and welded by argon arc welding. The interior of the box is smooth and without burrs. The lifting work platform is the working operation platform, and the lifting range of the platform is 380-3740, which meets the working height of all aircraft in use. The lifting cylinder is a single hydraulic cylinder, and the lifting mechanism is made of new aluminum alloy profiles. The platform is equipped with an electrical control switch assembly, which is used to control the water pump, the lift of the platform, and is equipped with night operation lights to facilitate night work.
Technical parameters of 4m³ aircraft water truck
Total length mm: 7190
Total width mm: 2100
Total height mm: 2260
Wheelbase mm: 3815
Wheel base (front/rear) mm: 1504/1425
Front suspension mm: 1025
Rear suspension mm: 2350
Approach Angle (°) : 22.5
Departure Angle (°) : 8
Longitudinal passage Angle (°) : 13
Minimum ground clearance mm: 200
Channel circle Outer circle mm: 17000
Maintenance weight kg: 4060
Water supply flow L/min: ≥150
Water tank volume L: 1400
Water supply pressure Mpa: 0.345
Volume of sewage tank (with/without vacuum pump) mm: 2360/2600
Platform lifting range mm: 385~3760
Vacuum tank volume (with/without vacuum pump) mm: 240/0
Maximum speed km/h: 80
Optional: Vacuum pump
Tank material/thickness mm: 0Cr18Ni9Ti/4.5
