The Passenger Stairs front platform is equipped with an operating device for fine adjustment of the angle of the ladder body and platform expansion and contraction, the platform is equipped with LED lighting, all parts in contact with the aircraft are fitted with non-scratch rubber strips, the platform and the front end of the sliding side panel are fitted with anti-collision rubber and photoelectric sensing switches which can effectively avoid collision with the fuselage of the aircraft.
Passenger Stairs Technical Parameters
Overall dimensions (L×W×H): 7450×2500×3600mm
Passenger Stairs Lifting Height Range : 2150~4800mm
Upper platform size ：4150mm*2200mm
Step size ：292mm*1500mm*192mm
Stroke of movable platform ： 0-400mm
Maximum angle between the ladder body and the level ：37.5°
Minimum ground clearance: 160mm
Outer diameter of channel circle ：16100mm
Front/rear wheelbase ：1685/1525mm
Overall mass ： 7550KG
Carrying capacity: 88 persons
Front axle load capacity: 2590kg
Rear axle load capacity: 4960kg
Maximum speed ：80
Minimum stabilized speed: 0.8
Drive motor power: 60kw
Total voltage: 618.24V
Total energy storage capacity ：Lithium iron phosphate battery 106.95kwh
Temperature range: -35～65
Battery energy density ：153.84Wh/kg
Wheelbase: 3360mm
